With APEX, we've reconfigured the Ring DAC's circuit board and developed a new analogue output stage. This has allowed us to further reduce distortion, and increase linearity, resulting in a range of measured and sonic improvements - including an even greater sense of dynamic drive, detail, finesse and vitality.
Compatible with all high-resolution music formats, from DSD to PCM, DXD and MQA, the Rossini is a system that can flex to serve whatever mood or music you ask it to. Whether you’re streaming or spinning discs, it provides stunning sound and an effortless listening experience.
Both the Rossini Player and DAC provide instant access to music from a wide range of sources - including streaming services, external devices and storage drives. In addition, each system offers internal upsampling and a choice of filtering options, allowing you to tailor its performance to suit your listening setup and musical tastes.
Playback is easily managed via our Mosaic control app, which allows you to browse music from multiple platforms - including Roon, TIDAL, Qobuz, Deezer, Spotify, Internet Radio and Apple Airplay - and control all of the settings on your system through a single, intuitive interface.
With the Rossini transport, you can experience stunning sound from CDs or SACDs, upsampling CD data to high-resolution DSD, DSD/128 or DXD for even greater resolution and detail, or playing both CDs and SACDs in their native formats. An additional downsampling option is also available for SACD data.
Dimensions (WxDxH) 444mm/17.5” x 435mm/17.2” x 125mm/5.0”. Allow extra depth for cable connectors.
Converter Type dCS proprietary Ring DACTM topology.
Digital Inputs Network interface on an RJ45 connector – Acts as a UPnPTM renderer in Asynchronous mode, streaming digital music from a NAS or local computer over a standard Ethernet network, decoding all major lossless formats including FLAC, WAV & AIFF at up to 24 bit 384kS/s native sample rate, plus DSD/64 & DSD/128 in DFF/DSF format.
Other supported formats include WMA, ALAC, MP3, AAC & OGG.
Some formats are limited to lower sample rates. Accepts data streamed from an iPod, iPhone or iPad via Apple AirPlay, 44.1 or 48kS/s only. Network Loop Out connector on a second RJ45 connector. USB 2.0 interface on a B-type connector operating in Asynchronous mode, will accept up to 24 bit PCM at up to 384kS/s plus DSD/64 & DSD/128 in DoP format. Operates in Class 1 or 2 mode.
USB-on-the-go interface on type A connector operating in Asynchronous mode, streams digital music from a flash drive at up to 24 bit 384kS/s plus DSD/64 or DSD/128.
2x AES/EBU on 3-pin female XLR connectors.
Each will accept PCM at up to 24 bit 192kS/s or DSD/64 in DoP format. Used as a Dual AES pair, it will accept PCM at up to 384kS/s, DSD/64 & DSD/128 in DoP format or dCS-encrypted DSD.
2x SPDIF on 1x RCA Phono and 1x BNC connectors. Each will accept PCM at up to 24 bit 192kS/s or DSD/64 in DoP format. 1x SPDIF optical on a Toslink connector will accept PCM at up to 24 bit 96kS/s.
Analogue Outputs Output levels: 2V or 6V rms for full-scale input, set in the menu. Balanced outputs: 1 stereo pair on 2x 3-pin XLR male connectors (pin 2 = hot, pin 3 = cold).
These outputs are electronically balanced and floating.
Output impedance is 3Ω, maximum load is 600Ω (10k-100kΩ is recommended).
Unbalanced outputs: 1 stereo pair on 2x RCA phono connectors.
Output impedance is 52Ω, maximum load is 600Ω (10k-100kΩ is recommended).
Word Clock I/O 2x Word Clock Inputs on 2x BNC connectors, accept standard word clock at 44.1, 48, 88.2, 96, 176.4 or 192kHz.
The data rate can be the same as the clock rate or an exact multiple of the clock rate. Sensitive to TTL levels. Word Clock Output on 1x BNC connector. In Master mode, a TTL-compatible word clock appears on this output.
Residual Noise 24-bit data: Better than -113dB0, 20Hz-20kHz unweighted. (6V output setting).
L-R crosstalk Better than -115dB0, 20Hz-20kHz.
Spurious Responses Better than -105dB0, 20Hz-20kHz.
Filters PCM mode: up to 6 filters give different trade-offs between the Nyquist image rejection and the phase response. DSD mode: 4 filters progressively reduce out-of-audio band noise level.
Upsampling Rates DXD as standard or optional DSD upsampling.
Software Updates Loaded from CD-R via PCM digital inputs or PC via USB input. Download and update functionality available via Rossini App.
Local Control dCS Rossini App for Unit Configuration and Music Playback. RS232 interface (controlled by a 3rd party automation system). IR remote control – dCS premium remote control available as an optional extra.
Power Supply Factory set to either 100, 115/120, 220 or 230/240V AC, 50-60Hz.
Power Consumption 23 Watts typical / 28 Watts maximum.
Operating Systems Windows Vista / 7 / 8.1 / 10, Mac OSX 10.10. dCS USB driver is required for Windows in Audio Class 2 Mode.
